Our range of fixing accessories for aluminium rails and profiles has been extended with the PLIOCATCH MU-Q200 and PLIOCATCH MU-Q200 SOLAR!
The PLIOCATCH range from SES-STERLING offers innovative and robust fixing solutions for a variety of industrial applications: electrical cabinets, machine construction, production automation, workstation design, etc.
PLIOCATCH clip-on cable fixing system
PLIOCATCH clips are a versatile fixing solution developed for machines and electrical cabinets.
Made from polyamide (PA), they are available in two colours, natural and black, and can be used in temperatures ranging from -40 to +85°C. The PLIOCATCH clip range comprises four models, each designed to meet specific requirements.
Thanks to their clip system, they can be installed quickly and without tools, considerably reducing installation time. Finally, their locking system makes it easy to add or remove cables.
PLIOCATCH GA-W, 1U-W and 2U-W mounting accessories
PLIOCATCH GA-W
PLIOCATCH GA-W is a cable fixing system designed for horizontal and vertical cable routing at the front or rear of electrical cabinets. Its capacity is equivalent to that of a 60 x 40 mm trunking.
The PLIOCATCH GA-W is mounted using a W clip, compatible with holes from 9.5 x 9.5 mm to 12.5 x 12.5 mm. It can be mounted on profiles, rails or perforated metal sheets with a thickness of 1.5 mm (for 9.5 x 9.5 mm holes) and 1.5 to 2.0 mm (for 10 x 10 to 12.5 x 12.5 mm holes).
The top of the cable block is hinged and has a clip closure that can be unlocked at any time, allowing the PLIOCATCH to be closed again once the cables are in place.
PLIOCATCH 1U-W et 2U-W
With widths adapted to the standards of 19″ racks for 1U and 2U strips, the PLIOCATCH 1U-W et 2U-W cable guide rings are designed for network applications.
They make it easy to insert or remove cables, jumpers or conductors from the top, while ensuring that they are held securely.
Fitted with a W clip, these rings can be mounted in holes with a cross-section of 11 x 11 mm up to 13 x 13 mm, with a maximum sheet thickness of 1.7 mm, and are compatible with other uprights and profiles with square holes.
PLIOCATCH MU-Q200 and MU-Q200 SOLAR cable blocks
PLIOCATCH MU-Q200
The PLIOCATCH MU-Q200 is a polyamide cable block, available in natural and black.
Designed for fixing cables to type I and M aluminium profiles with an 8 mm groove, it can withstand temperatures from -40 to +85°C. Its tool-free installation and quarter-turn lock make it a practical and quick-to-install accessory.
It can be used horizontally or vertically, and is ideal for machine building, production automation, workstation design and electrical cabinets.
PLIOCATCH MU-Q200 SOLAR
The PLIOCATCH MU-Q200 SOLAR is a variation of the PLIOCATCH MU-Q200, specially designed for the photovoltaic industry.
The cable block is fixed to solar aluminium profiles with an 8.8 mm groove. Thanks to its hammer head, it can be locked with a simple quarter-turn, without the need for tools.
Space-saving and non-lockable, it can be used to quickly add conductors by simply pressing, and to run cables horizontally or vertically on photovoltaic installations.
PLIOCATCH screw-in cable blocks
PLIOCATCH screw-in cable blocks are designed to secure cables in various electrical installations (electrical cabinets, machines, etc.) using screws.
Available in two colours, black and natural, five models make up the PLIOCATCH screw-in range. To suit different configurations, several different closing systems make it easy to add or remove cables.
PLIOCATCH DELTA L and M cable guides
With a capacity equivalent to that of a 60×40 mm trunking, but taking up very little space, the PLIOCATCH DELTA allows cables to pass through, even in confined spaces (rows of switchgear, for example).
The cable guide is designed for horizontal cable routing at the back or front of modular units mounted on a double DIN profile or OMEGA DIN rail. There are four possible configurations: on a double DIN rail (DELTA M front or rear) and on an OMEGA DIN rail (DELTA M front and DELTA L rear on the 6.2 x 15 mm slotted hole).
Would you like to find out about other cable fixing systems? Explore the new SES-STERLING catalogue.
To find out more, please contact us.
